AI-Powered FOIA Data Extraction for Academic Analysis

The research challenge involved handling inconsistent document layouts across thousands of scanned FOIA files. Traditional extraction tools lacked the flexibility to adapt. Specific blockers included:

• Unstructured formats with three distinct layout types.
• Scanned image inputs that prevented direct text parsing.
• Visual field indicators, such as bolded text, that traditional OCR tools ignored.
• Split and merged fields across rows and columns, leading to alignment errors.
• Page-level formatting drift that created row misalignment in exported data.

Without automation, the project would have required months of manual data entry, making it impractical for time-bound academic work and limiting the potential for large-scale analysis.

To address the complexity of scanned FOIA pages, a five-stage technical solution was implemented. Each stage was carefully designed to ensure both automation and interpretability:

Using PyPDF2, the document corpus was divided into smaller, manageable batches. Each file was processed in segments of 100 pages, further split into 10-page units to minimize formatting contamination. Segmentation allowed targeted extraction logic to adapt to subtle shifts in document structure and prevented the AI model from inheriting faulty layouts across unrelated sections.

NextGen’s approach improved fault isolation, enabling consistent QA controls at the batch level and reducing reprocessing overhead by nearly 30%.

Converting Pages to High-Quality Images

To maximize OCR fidelity, each PDF page was transformed into a high-resolution image via pdf2image. The PIL (Pillow) library was then used to resize, sharpen, and standardize image dimensions. NextGen’s enhancements ensured clean visual inputs for the AI model, even in cases of faded ink or skewed scans.

The image pre-processing routine also integrated google.api_core.exceptions for robust error handling, allowing failed conversions to be retried without compromising batch integrity.

Reading and Understanding the Content

Using the Google Gemini API, each batch of 10 enhanced images was parsed by a multimodal large language model trained for visual-textual interpretation. The model inferred data structure, identified semantic groupings based on bold text cues, and classified information into discrete fields such as Establishment Number, DBA, and Grant Date.

Where residual text was partially machine-readable, pdfminer.six was deployed to complement the LLM’s output. Final structuring was handled using pandas, ensuring column alignment and schema consistency.

NextGen’s inference process included retry logic, error logging, and dynamic adaptation to each format variant.

Cleaning and Structuring the Data

Raw extractions were normalized using pandas to resolve inconsistencies. The pipeline corrected column drift, addressed null or malformed entries, and standardized field formats (e.g., addresses and dates). Each 100-page group was validated individually to prevent systemic contamination.

Data integrity checks included uniqueness tests, schema conformance validation, and duplicate filtering. NextGen’s process enhanced batch consistency and made downstream statistical modeling reliable.

Exporting to Spreadsheet Format

The final datasets were exported using pandas.to_csv(), producing individual CSVs for every batch. The files were later merged into a master Excel workbook compatible with econometrics tools. Field names were validated against original source labels, allowing seamless alignment with the researcher’s analytical framework.

NextGen’s streamlined format enabled direct plug-and-play within existing Booth research models.

• Accuracy: Proof-of-concept achieved 99% character-level accuracy (406/410 entries correct), full-scale processing maintained >90%.
• Cost Savings: Delivered under $3,000, compared to $8,000 from other vendors.
• Processing Speed: 25,000 pages processed in <4 weeks using intelligent batching.
• QA Efficiency: Two-layer validation system caught 95% of alignment and content issues.

Impact: Enabled timely, clean data access for advanced regression and classification research.

The case demonstrates the operational scalability of combining AI-based inference with human-in-the-loop QA for high-stakes academic use cases. The structured dataset not only empowered Booth’s research into industrial trends but also validated a repeatable pipeline design for:

• Legal reviews involving scanned case files
• Government compliance audits using legacy formats
• Financial modeling on scanned annual reports

The LLM-driven architecture is scalable to millions of pages and reproducible across other verticals requiring structured output from scanned materials.
